本课程属于高级射频集成电路设计培训课程，适合具有一定基础的学员：偏重设计中的实际问题，RFIC权威教授：Prof. Thomas H. Lee和Prof. C. Patrick Yue在上海、Prof. Asad A. Abidi在合肥为我们带来以下课程内容：

CMOS RF IC Design

（Prof. Thomas H. Lee, August 26, 2014,Shanghai）

1、Impedance transformation

   ▲When to do it; When not to do it; how to do it

▲Bode-Fano limits on matching bandwidth

▲Unintended transformation by active circuits: "Strange impedance behaviors (SIBs); simple models and examples

▲Conscious exploitation of SIBs

2、Noise in linear, time-invariant (LTI) systems

▲LNA design: Noise match vs. power match

▲How to use SIBs to achieve good noise and power match simultaneously

▲Noise "cancellation"

3、Noise in linear, time-varying (LTV) systems

▲Phase noise in oscillators: Theory and practice

▲Noise in mixers

4、Nonlinearity

▲Figures of merit: 1-dB compression point; intermodulation intercepts (IP2, IP3); adjacent-channel power ratio (ACPR); spurious-free dynamic range (SFDR)

▲Nonlinearity reduction techniques: Feedback; strong and weak feedforward

5、Techniques for circuit design at extremes of frequency

▲Amplifier bandwidth extension techniques: Shunt peaking; bridged T-coil; distributed architectures; Ft-doubler

▲Oscillator and synthesizer frequency extension techniques: Multiphase push-push-push; frequency multiplication with nonlinear elements; injection locking (if time permits)

▲Power combining structures and strategies: Corporate combiners; free-space combining

▲Interconnect: Microstrip, stripline, coplanar waveguide

Practical RFIC Implementation Techniques in Scaled CMOS Technologies

（Prof. C. Patrick Yue, August 27, 2014,Shanghai）

1、CMOS for RFIC Products

▲Trends in wireless communication and RFIC integration

▲RF technology options: to use or not to use?

▲Scalability of RF CMOS beyond 130nm: device characteristics and passive component quality at RF

2、RF Device and Passive Component Modeling

▲MOSFET macro modeling and layout optimization

▲Physical modeling and layout optimization for inductors

▲Transformer design trade-offs and circuit applications

▲Varactor modeling and optimization – diode vs. MOS

▲Test structure design and characterization techniques

3、 Technology Key Circuit Blocks

▲T/R switch – improve P-1dB and isolation with tuned circuits

▲LNA – topology, sizing and biasing for noise and power

▲Mixer – topology, linearity and noise considerations

▲VCO – phase noise, power and tuning range optimization

4、 Modeling, Substrate Noise and ESD Techniques

▲Methodology for predictable design using RF sub-circuits

▲Supply and substrate noise coupling

▲RF ESD protection strategy from a system perspective

Systematic Design of Oscillator Circuits

（Prof. Asad A. Abidi, August 30, 2014,Hefei）

In this one day tutorial/short course, Prof. Asad A. Abidi will present his unique highly valued training methods and contents of oscillator design based on fundamental analysis and calculation, not the common PDK-based and EDA-based “error-and-try” optimization. It will most benefit circuit designers in industry involved with oscillators and frequency synthesizers.

▲Noise processes in CMOS oscillators;

▲Time-domain jitter calculation;

▲Effects of white noise and flicker noise etc.;

▲What dominates the jitter and phase noise?

▲Where are they arise from?

▲Theocratic analysis and design of circuits with validation;

▲Straightforward expressions for period jitter and phase noise enable manual design;

▲Design guidance from ring and LC oscillator.
